MultiSelect Attribute

Docusaurus logo

How to use in JSON metadata in form builder:

{
  "id": "multiselect",
  "new_id": "select",
  "is_standard": true,
  "editable": true,
  "display_order": 11,
  "select_icon": "menu-down",
  "label": "MultiSelect field",
  "input_type": "MULTISELECT",
  "input_options": [],
  "placeholder_text": "Placeholder",
  "initial_value": "",
  "background_color": "primary.300",
  "mode": "outlined",
  "validation_rules": {}
}

Properties of multiSelect attribute:

#	Attribute	Default	Description
1	id	multiselect	This value won't change!
2	new_id		New attribute id to use in form
3	is_standard	true
4	editable	true	Allows user to edit the input field
5	display_order	1	Allows user to define the order of the fields
6	select_icon	menu-down	Helps to add icon to the field eg: iconName from vector Icon (https://pictogrammers.com/library/mdi/?welcome)
7	label	Select field	Used to specify the label of the field
8	input_type	MULTISELECT	Base attribute which specifies input types. (no need to change)
9	input_options	[]	Here you have to specify about the option you need in dropdown
10	placeholder_text	Placeholder	Placeholder temporarily takes the place of the final data
11	initial_value	" "	It defines the initial value in the input field
12	background_color	white	Theme colors can be used here. e.g. primary.100 or red.300
13	mode	outlined	'flat' or 'outlined' Check mode value from https://callstack.github.io/react-native-paper/docs/components/TextInput/
14	validation_rules		https://react-hook-form.com/get-started#IntegratingControlledInputs -> `rules`
